★Integrated with incubator and shaker to save space and cost.
★ABS shell, polished stainless steel chamber.
★Large LCD screen to display temperature and shaking speed.
★With operation data memory function to eliminate faulty operation.
★ Non-volatile memory saves settings during a power outage and automatically restarts the unit as originally programmed after power is restored.
★Auto-stop operation when door is opened. Strong air spring rod with easy opening and closing.
★ Brushless DC motor, more stable and reliable.
★ Equipped with leakage protection.

Model
LYZ-103B
LYZ-100B
LYZ-200B
Shaking Speed (rpm)
20-300
Speed accuracy (rpm)
±1
Swing amplitude（mm）
Φ26
Standard configuration
100ml×9
50ml×4, 100ml×4 ,250ml×3, 500ml×3
50ml×5, 100ml×5 ,250ml×4, 500ml×3
Maximum capacity
50ml×12,100ml×9
50ml×20 or 100ml×16 or 250ml×12 or 500ml×9
100ml×20 or 250ml×16 or 500ml×12 or 1000ml×5 or 2000ml×4
Tray Size（mm）
295×253
400×370
450×410
Timing Range
1-9999min
Temperature Range（℃）
RT+5～60
RT+5～60
4～60(Cooling)
Temperature Accuracy （℃）
±0.1
Temperature uniformity（℃）
±1
Display
LCD
Tray Included
1
Exterior Size(W×D×H)mm
440×410×390
600×580×510
780×682×560
Package Size (W×D×H)mm
580×530×540
740×700×660
920×800×610
Net/Gross weight(kg)
31/41
72/88
100/125
Volume (W×D×H)mm
320×295×190
440×405×270
480×450×320
Power Rating
220W
320W
580W
Power Supply
AC 220～240V, 50～60Hz
